| Product | Welded large-profile stainless steel rectangular tube / stainless steel flat tube |
|---|---|
| External Size | 80*180mm |
| Approx. Inch Size | 3.150″ * 7.087″; metric dimensions control the order |
| Wall Thickness | 1.5mm, 2.0mm, 2.5mm, 3.0mm, 3.5mm, 4.0mm, 5.0mm and 6.0mm |
| Material Grades | AISI 201, 304/304L and 316/316L |
| Reference Standard | ASTM A554; project-specific requirements must be confirmed before production |
| Surface Options | 2B, BA, No.4, brushed, satin, hairline and mirror; custom finish by agreement |
| Standard Lengths | 5.85m, 6m, 6.1m and 7m; custom cut length available |
| Processing | Cutting, drilling, laser cutting, bending review, welding, polishing and end finishing |
| Typical Uses | Frames, railing components, partitions, door structures, furniture and architectural fabrication |
| Specified Metric Size | 80.0mm * 180.0mm |
|---|---|
| Decimal Inch Conversion | 3.150″ * 7.087″ |
| Rounded Inch Reference | Approximately 3.15″ * 7.09″ |
| Comparison with 3″ * 7″ | Exact 3″ * 7″ is 76.2mm * 177.8mm and is not the same size |
| Purchase Instruction | Order by the 80*180mm drawing dimensions and tolerance. Do not substitute a rounded inch size without checking mating parts, brackets and fabrication drawings. |
