Home > Products > Stainless Steel Inox > Acid And Alkali Resistance 219mm Diameter Inox Tube 201 304 316 Grade Large OD Thick Wall Stainless Steel Round Pipe

Acid And Alkali Resistance 219mm Diameter Inox Tube 201 304 316 Grade Large OD Thick Wall Stainless Steel Round Pipe

Product Details

Place of Origin: Guangdong,China

Brand Name: WinscoMetal

Certification: ISO,SGS,TUV,MTC,Third Party From Customers

Model Number: WI85

Payment & Shipping Terms

Minimum Order Quantity: 5 Ton or Negotiable

Price: Negotiable

Packaging Details: Stainless Steel Pipe And Tubing: A- one pcs sleeve in plastic bag and then packed by weaving bundle; B- Bundle weight 50 kg max; C- Ink marking on a sticker must stick on each tube and each weaving bundle; D-Customer's logo can be made on pipe or poly bag;

Delivery Time: 7-15 work days

Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram

Supply Ability: 3000 Ton/Tons per Month

Get Best Price
Highlight:
Keyword:
219mm Stainless Steel Inox Round Tube Pipe,Tubo De Acero Inoxidable
Material:
SS 201, SS 304, SS 304L, SS 316,SS 316L
Thickness:
1.0mm-7.0mm,etc.
Surface:
Mirror,Hairline,PVD Color Or Customized.
Tolerance:
±3%,±5%,±10%
Length:
5.85m,6m,6.1m,7m,length Can Be Customized.
Processing Service:
Bending, Welding, Decoiling, Punching, Cutting, Moulding
Application:
For Construction/shipbuilding/elevator Industy, Etc.
Welding Type::
TIG Welded,Longitudinally Welded Pipes,ERW
Standard:
ASTM A554 / JIS G3446 / CNS 5802 / EN 10217-7 / EN 10296-2,EN 10305-2,EN 10305-5.
Keyword:
219mm Stainless Steel Inox Round Tube Pipe,Tubo De Acero Inoxidable
Material:
SS 201, SS 304, SS 304L, SS 316,SS 316L
Thickness:
1.0mm-7.0mm,etc.
Surface:
Mirror,Hairline,PVD Color Or Customized.
Tolerance:
±3%,±5%,±10%
Length:
5.85m,6m,6.1m,7m,length Can Be Customized.
Processing Service:
Bending, Welding, Decoiling, Punching, Cutting, Moulding
Application:
For Construction/shipbuilding/elevator Industy, Etc.
Welding Type::
TIG Welded,Longitudinally Welded Pipes,ERW
Standard:
ASTM A554 / JIS G3446 / CNS 5802 / EN 10217-7 / EN 10296-2,EN 10305-2,EN 10305-5.
Acid And Alkali Resistance 219mm Diameter Inox Tube 201 304 316 Grade Large OD Thick Wall Stainless Steel Round Pipe

Acid And Alkali Resistance 219mm Diameter Inox Tube 201 304 316 Grade Large OD Thick Wall Stainless Steel Round Pipe



In what acid and alkaline environments is 219mm Diameter Inox Tube 201 304 316 Grade Large OD Thick Wall Stainless Steel Round Pipe corrosion resistant?
The corrosion resistance of the 219mm Diameter Inox Tube 201 304 316 Grade Large OD Thick Wall Stainless Steel Round Pipe can vary depending on the specific grade of stainless steel used (AISI201, AISI304, AISI316) and the concentration and temperature of the acid or alkaline environment. Here is a general overview of the corrosion resistance of these stainless steel grades in different acid and alkaline environments:
1. AISI201:
- Corrosion Resistance: AISI201 offers good resistance to corrosion in mildly corrosive environments and low concentrations of acids. It performs well in neutral and alkaline environments.
2. AISI304:
- Corrosion Resistance: AISI304 provides excellent corrosion resistance in a wide range of environments, including many acids at various concentrations and temperatures. It is resistant to organic acids, such as acetic acid and formic acid, and inorganic acids, including sulfuric acid and phosphoric acid, at moderate concentrations and temperatures. However, it may experience localized corrosion in highly concentrated or hot solutions of certain acids, such as hydrochloric acid or nitric acid.
3. AISI316:
- Corrosion Resistance: AISI316 has superior corrosion resistance compared to AISI304, particularly in chloride-containing environments. It offers excellent resistance to a variety of acids, including sulfuric acid, hydrochloric acid, and phosphoric acid, at various concentrations and temperatures. AISI316 is also highly resistant to alkalis and caustic solutions.
It's important to note that the corrosion resistance of stainless steel is influenced by factors such as concentration, temperature, exposure time, presence of other chemicals, and the specific environment. In highly aggressive or extreme conditions, even corrosion-resistant stainless steels may experience some degree of corrosion.



Acid And Alkali Resistance What is the surface treatment of 219mm Diameter Inox Tube 201 304 316 Grade Large OD Thick Wall Stainless Steel Round Pipe? Is it corrosion and abrasion resistant?
The surface treatment of the 219mm Diameter Inox Tube 201 304 316 Grade Large OD Thick Wall Stainless Steel Round Pipe can vary depending on the manufacturer and specific requirements. Common surface treatments for stainless steel pipes include:
1. Pickling and Passivation: This treatment involves removing surface impurities and forming a passive oxide layer to enhance corrosion resistance. It is a standard treatment for stainless steel pipes.
2. Polishing: Stainless steel pipes can be polished to improve their appearance and provide a smoother surface. Polishing does not significantly impact corrosion resistance but can make the surface more resistant to abrasion.
3. Coatings: Some stainless steel pipes may undergo additional coating processes to provide extra protection against corrosion and abrasion. Common coatings include epoxy, polyethylene, or zinc.
Regarding corrosion and abrasion resistance, stainless steel is generally known for its corrosion-resistant properties. AISI201, AISI304, and AISI316 stainless steel grades all offer good corrosion resistance in various environments. However, it's important to note that no material is completely immune to corrosion or abrasion.
The corrosion and abrasion resistance of the 219mm Diameter Inox Tube 201 304 316 Grade Large OD Thick Wall Stainless Steel Round Pipe will depend on factors such as the specific grade of stainless steel used, the manufacturing process, the surface treatment applied, and the specific corrosive or abrasive environment it is exposed to.
Proper surface treatment, such as pickling and passivation, can enhance the corrosion resistance of stainless steel pipes. Additionally, a smooth and polished surface can offer some resistance to abrasion. However, in highly corrosive or abrasive environments, it may be necessary to consider additional protective measures, such as specialized coatings or alloys designed for specific applications.


Specifications:

Length: 6m                             Unit: KG/support

           Thickness
      Weight
 Size



0.91mm 1.11mm 1.14mm 1.91mm 2.4mm 3mm 3.5mm 4mm 4.5mm 5mm 6mm 7mm 8mm
127mm 17.15 20.89 28.32 35.71 44.69 55.6 64.6 73.53 82.39 91.17
133mm 18.01 21.9 29.8 37.8 46.85 58.29 67.74 77.12 86.43 95.65 113.89
141mm   23.21 29.42 39.71 49.72 61.88 71.93 81.9 91.81 101.63 121.06
159mm   26.19 33.21 44.84 56.17 69.85 81.34 92.67 103.91 115.08 137.2
168mm   27.69 35.11 47.41 59.4 73.98 86.05 98.05 109.97 121.81 145.28
178mm     37.21 50.27 62.99 78.47 91.28 104.02 116.69 129.28 154.24
203mm     42.48 57.4 71.96 89.68 104.36 118.97 133.51 147.97 176.66 205.06
219mm     49.21 61.97 77.7 96.85 112.73 128.54 144.27 159.92 191.01 221.8
254mm       71.96 90.25 112.54 131.04 149.46 167.81 186.08 222.40 258.42 294.14
273mm       77.39 97.07 121.06 140.98 160.82 180.59 200.28 239.43 278.29 316.86
306mm       86.81 108.9 135.86 158.24 180.55 202.78 224.94 269.03 312.82 356.31
325mm       92.23 115.72 144.38 168.18 191.91 215.56 239.14 286.07 332.07 379.03
356mm       101.08 128.64 158.28 184.40 21.44 236.41 262.30 313.87 365.13 416.10
377mm         134.37 167.69 195.38 222.99 250.53 278.00 332.70 387.10 441.21
406mm         144.77 180.70 210.55 240.33 270.04 299.67 358.70 417.44 475.88
426mm         151.95 189.66 221.01 252.29 283.49 314.61 376.64 438.37 499.79
480mm         171.32 213.88 249.26 284.57 319.81 354.97 425.06 494.86 564.36
80mmx80mm 13.86 16.9 21.47 29.08 36.54 45.68 53.29 60.90
90mmx90mm 15.59 18.67 19.34 32.18 40.26 50.06 58.14 66.15
50mmx100mm 12.9 15.73 21.41 27.08 34.26 42.82 49.96 57.1
60mmx100mm 13.76 16.8 22.85 28.29 36.54 45.68 53.29 60.9
80mmx100mm 15.59 19.01 24.15 32.72 41.11 51.39 59.95 68.52
100mmx100mm 17.23 21.02 26.7 36.17 45.45 56.81 66.28 75.75
40mmx120mm 13.76 16.8 22.85 28.89 36.54 45.68 53.29 60.9
60mmx120mm 15.5 18.9 25.7 32.53 41.11 51.39 59.95 68.52
80mmx120mm   21.13 26.84 36.35 45.68 57.1 66.64 76.13 85.64
100mmx120mm     29.52 39.99 50.24 62.81 73.27 83.74 94.21 104.68 125.61
120mmx120mm     32.2 43.62 54.81 68.52 79.93 91.35 102.77 114.19 137.03
50mmx150mm   21.13 26.84 36.35 45.68 57.10 66.61 76.13 85.64
100mmx150mm     35.78 45.25 57.10 71.37 83.27 95.16 107.06 118.95 142.74 166.53 190.32
150mmx150mm     40.25 54.53 68.52 85.64 99.92 114.19 128.47 142.74 171.29 199.84 228.38
80mmx160mm     32.2 43.62 54.81 68.52 79.93 91.35 102.77 114.19 137.03
80mmx180mm       65.43 82.22 102.77 119.90 137.03 154.16 171.29 205.55
100mmx200mm       54.53 68.52 85.64 99.92 114.19 128.47 142.74 171.29 199.84 228.38
150mmx200mm         79.93 99.92 116.57 133.32 149.88 166.53 199.84 233.14 266.45
150mmx300mm         102.3 125.8 148.9 170 191.4 212.6 255 297 338.7
200mmx200mm         91.35 114.19 133.22 152.26 191.29 190.32 228.38 266.45 304.51
250mmx250mm         104.19 142.74 166.53 190.32 214.11 237.9 285.48 333.06 380.64
300mmx300mm         137.03 171.29 199.84 228.38 256.93 285.48 342.58 399.67 456.77
350mmx350mm           199 231.8 264 296.
Special specifications,length and wall thickness can be customized according to customer requirements.



Description

Tube En Inox;Tig Welded Stainless Steel Pipe;Stainless steel tubes; stainless steel welded pipe; 219mm stainless steel inox round tube pipe;Tubo de acero inoxidable

Material Grade AISI201/SUS304/ AISI316
Standard

ASTM A554/JIS G3446 /CNS 5802 /EN 10217-7/EN 10296-2,EN 10305-2,EN 10305-5.

Thickness

1.0mm,1.5mm,2.0mm,2.5mm,3.0mm,3.5mm,4.0mm,5.0mm,6.0mm,7.0mm,customized.

Section Shape Round Shape.
Surface BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D
Length 5.85m,6m,6.1m,7m,length can be customized.
Application It widely used in auto parts, hardware tools, handicrafts, electronics, textiles, chemicals, machinery, construction, aerospace, winding various precision springs,hangers,elevator, machinery industry, shipbuilding industry, pharmaceutical industry and etc.



Acid And Alkali Resistance What applications with larger flow or strength requirements are suitable for 219mm Diameter Inox Tube 201 304 316 Grade Large OD Thick Wall Stainless Steel Round Pipe?
The 219mm Diameter Inox Tube 201 304 316 Grade Large OD Thick Wall Stainless Steel Round Pipe, with its larger diameter and thick wall, can be suitable for various applications that require larger flow or have higher strength requirements. Here are some examples:
1. Industrial Piping Systems: The pipe can be used for industrial piping systems that require the transportation of fluids or gases with larger flow rates. This includes applications in chemical plants, petrochemical facilities, oil and gas refineries, power plants, and other industrial settings.
2. Water and Wastewater Treatment: The pipe can be utilized in water treatment plants, wastewater treatment plants, and desalination facilities for the conveyance of water, treated wastewater, and chemicals.
3. Mining and Minerals Processing: The pipe can be suitable for mining operations and mineral processing plants, where there is a need for large-scale conveyance of ore, slurries, and chemicals.
4. Oil and Gas Industry: It can be used in the oil and gas industry for pipelines, especially in applications where larger flow rates or higher pressure requirements are necessary.
5. HVAC (Heating, Ventilation, and Air Conditioning): The pipe can be employed in large-scale HVAC systems, particularly in commercial or industrial buildings where substantial airflows are required.
6. Power Generation: The pipe can find application in power generation facilities, including thermal power plants, nuclear power plants, and renewable energy installations, where high-pressure steam or other fluids need to be transported.
7. Infrastructure Projects: It can be utilized in infrastructure projects such as water supply systems, sewage systems, and large-scale irrigation systems.
8. Chemical Processing: The pipe can be employed in various chemical processing applications, including the transport of corrosive chemicals, acids, and solvents.
9. Food and Beverage Industry: The pipe can be suitable for food processing facilities, breweries, and beverage production plants, where large volumes of liquids or gases need to be transported.
10. Pharmaceutical and Biotechnology Industry: It can find utility in pharmaceutical manufacturing and biotechnology applications that require large-scale fluid transfer or processing.
These applications represent some of the potential uses for the 219mm Diameter Inox Tube 201 304 316 Grade Large OD Thick Wall Stainless Steel Round Pipe. However, the specific suitability of the pipe for a particular application depends on factors such as the fluid or gas being transported, the required flow rates, pressure conditions, and compatibility with the specific environment. It is recommended to consult with engineers and industry experts to determine the most appropriate stainless steel grade and pipe specifications for your specific application.
