Home > Products > Stainless Steel Inox > High Temperature Resistance 159mm Inox Welded Tube AISI201 304 316 Large Diameter Round Stainless Steel Thick Wall Pipe

High Temperature Resistance 159mm Inox Welded Tube AISI201 304 316 Large Diameter Round Stainless Steel Thick Wall Pipe

Product Details

Place of Origin: Guangdong,China

Brand Name: WinscoMetal

Certification: ISO,SGS,TUV,MTC,Third Party From Customers

Model Number: WI84

Payment & Shipping Terms

Minimum Order Quantity: 1 Ton or Negotiable

Price: Negotiable

Packaging Details: Stainless Steel Pipe And Tubing: A- one pcs sleeve in plastic bag and then packed by weaving bundle; B- Bundle weight 50 kg max; C- Ink marking on a sticker must stick on each tube and each weaving bundle; D-Customer's logo can be made on pipe or poly bag;

Delivery Time: 7-15 work days

Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram

Supply Ability: 3000 Ton/Tons per Month

Get Best Price
Highlight:
Keyword:
159mm Stainless Steel Inox Round Tube Pipe,Tubo De Acero Inoxidable
Material:
SS 201, SS 304, SS 304L, SS 316,SS 316L
Thickness:
1.0mm-6.0mm,etc.
Surface:
Mirror,Hairline,PVD Color Or Customized.
Tolerance:
±3%,±5%,±10%
Length:
5.85m,6m,6.1m,7m,length Can Be Customized.
Processing Service:
Bending, Welding, Decoiling, Punching, Cutting, Moulding
Application:
For Construction/shipbuilding/elevator Industy, Etc.
Welding Type::
TIG Welded,Longitudinally Welded Pipes,ERW
Standard:
ASTM A554 / JIS G3446 / CNS 5802 / EN 10217-7 / EN 10296-2,EN 10305-2,EN 10305-5.
Keyword:
159mm Stainless Steel Inox Round Tube Pipe,Tubo De Acero Inoxidable
Material:
SS 201, SS 304, SS 304L, SS 316,SS 316L
Thickness:
1.0mm-6.0mm,etc.
Surface:
Mirror,Hairline,PVD Color Or Customized.
Tolerance:
±3%,±5%,±10%
Length:
5.85m,6m,6.1m,7m,length Can Be Customized.
Processing Service:
Bending, Welding, Decoiling, Punching, Cutting, Moulding
Application:
For Construction/shipbuilding/elevator Industy, Etc.
Welding Type::
TIG Welded,Longitudinally Welded Pipes,ERW
Standard:
ASTM A554 / JIS G3446 / CNS 5802 / EN 10217-7 / EN 10296-2,EN 10305-2,EN 10305-5.
High Temperature Resistance 159mm Inox Welded Tube AISI201 304 316 Large Diameter Round Stainless Steel Thick Wall Pipe

High Temperature Resistance 159mm Inox Welded Tube AISI201 304 316 Large Diameter Round Stainless Steel Thick Wall Pipe



What are the material specifications of High Temperature Resistance 159mm Inox Welded Tube AISI201 304 316 Large Diameter Round Stainless Steel Thick Wall Pipe? What are the characteristics of AISI201, 304 and 316 respectively?
The material specifications of a High Temperature Resistance 159mm Inox Welded Tube AISI201 304 316 Large Diameter Round Stainless Steel Thick Wall Pipe are as follows:
- Material: Stainless steel
- Grades: AISI201, AISI304, AISI316
- Outer Diameter: 159mm
- Type: Welded tube
- Wall Thickness: Thick wall pipe
Now let's explore the characteristics of AISI201, AISI304, and AISI316 stainless steels:
1. AISI201:
- It is a low-nickel stainless steel with a higher manganese content.
- It offers good resistance to corrosion and oxidation.
- AISI201 has lower cost compared to AISI304 and AISI316.
- It is often used in environments that require moderate corrosion resistance.
2. AISI304 (also known as 18/8 stainless steel):
- It is the most widely used stainless steel grade.
- AISI304 offers excellent corrosion resistance, even in harsh environments.
- It has good welding and forming properties.
- AISI304 is suitable for various applications, including food processing, kitchen equipment, and architectural purposes.
3. AISI316 (also known as marine grade stainless steel):
- It contains molybdenum, which enhances its corrosion resistance, especially against chlorides and acids.
- AISI316 has superior pitting and crevice corrosion resistance compared to AISI304.
- It has excellent high-temperature strength and can withstand elevated temperatures.
- AISI316 is commonly used in marine environments, chemical processing plants, and medical applications.
In summary, AISI201, AISI304, and AISI316 have different compositions and properties. AISI201 is a low-nickel stainless steel with moderate corrosion resistance, while AISI304 is a widely used stainless steel with excellent corrosion resistance. AISI316, on the other hand, offers superior corrosion resistance, particularly in harsh environments, and has excellent high-temperature strength. The choice of grade depends on the specific application requirements, considering factors such as corrosion resistance, cost, and environmental conditions.



What are the mechanical properties of High Temperature Resistance 159mm Inox Welded Tube AISI201 304 316 Large Diameter Round Stainless Steel Thick Wall Pipe? Does it have sufficient strength and durability?

The mechanical properties of the High Temperature Resistance 159mm Inox Welded Tube AISI201 304 316 Large Diameter Round Stainless Steel Thick Wall Pipe can vary depending on the specific grade of stainless steel used (AISI201, AISI304, AISI316) and the manufacturing process. However, I can provide you with a general overview of the typical mechanical properties of these stainless steel grades:
1. AISI201:
- Tensile Strength: 520-690 MPa (75-100 ksi)
- Yield Strength: 260-380 MPa (38-55 ksi)
- Elongation: 40-50%
- Hardness: HRB<95, HB<241
2. AISI304:
- Tensile Strength: 515-620 MPa (75-90 ksi)
- Yield Strength: 205-260 MPa (30-38 ksi)
- Elongation: 40-60%
- Hardness: HRB<90, HB<187
3. AISI316:
- Tensile Strength: 515-620 MPa (75-90 ksi)
- Yield Strength: 205-260 MPa (30-38 ksi)
- Elongation: 40-60%
- Hardness: HRB<90, HB<187
These mechanical properties indicate the strength, yield strength, ductility (elongation), and hardness of the stainless steel grades. They demonstrate the ability of the material to withstand mechanical stress and deformation. The values provided are typical ranges and may vary depending on the specific product and manufacturing process.
In terms of strength and durability, stainless steel, including AISI201, AISI304, and AISI316, is known for its excellent mechanical properties and corrosion resistance. These grades of stainless steel are commonly used in various industries and applications where strength, durability, and resistance to corrosion are important factors.


Specifications:

Length: 6m                             Unit: KG/support

           Thickness
      Weight
 Size



0.91mm 1.11mm 1.14mm 1.91mm 2.4mm 3mm 3.5mm 4mm 4.5mm 5mm 6mm 7mm 8mm
127mm 17.15 20.89 28.32 35.71 44.69 55.6 64.6 73.53 82.39 91.17
133mm 18.01 21.9 29.8 37.8 46.85 58.29 67.74 77.12 86.43 95.65 113.89
141mm   23.21 29.42 39.71 49.72 61.88 71.93 81.9 91.81 101.63 121.06
159mm   26.19 33.21 44.84 56.17 69.85 81.34 92.67 103.91 115.08 137.2
168mm   27.69 35.11 47.41 59.4 73.98 86.05 98.05 109.97 121.81 145.28
178mm     37.21 50.27 62.99 78.47 91.28 104.02 116.69 129.28 154.24
203mm     42.48 57.4 71.96 89.68 104.36 118.97 133.51 147.97 176.66 205.06
219mm     49.21 61.97 77.7 96.85 112.73 128.54 144.27 159.92 191.01 221.8
254mm       71.96 90.25 112.54 131.04 149.46 167.81 186.08 222.40 258.42 294.14
273mm       77.39 97.07 121.06 140.98 160.82 180.59 200.28 239.43 278.29 316.86
306mm       86.81 108.9 135.86 158.24 180.55 202.78 224.94 269.03 312.82 356.31
325mm       92.23 115.72 144.38 168.18 191.91 215.56 239.14 286.07 332.07 379.03
356mm       101.08 128.64 158.28 184.40 21.44 236.41 262.30 313.87 365.13 416.10
377mm         134.37 167.69 195.38 222.99 250.53 278.00 332.70 387.10 441.21
406mm         144.77 180.70 210.55 240.33 270.04 299.67 358.70 417.44 475.88
426mm         151.95 189.66 221.01 252.29 283.49 314.61 376.64 438.37 499.79
480mm         171.32 213.88 249.26 284.57 319.81 354.97 425.06 494.86 564.36
80mmx80mm 13.86 16.9 21.47 29.08 36.54 45.68 53.29 60.90
90mmx90mm 15.59 18.67 19.34 32.18 40.26 50.06 58.14 66.15
50mmx100mm 12.9 15.73 21.41 27.08 34.26 42.82 49.96 57.1
60mmx100mm 13.76 16.8 22.85 28.29 36.54 45.68 53.29 60.9
80mmx100mm 15.59 19.01 24.15 32.72 41.11 51.39 59.95 68.52
100mmx100mm 17.23 21.02 26.7 36.17 45.45 56.81 66.28 75.75
40mmx120mm 13.76 16.8 22.85 28.89 36.54 45.68 53.29 60.9
60mmx120mm 15.5 18.9 25.7 32.53 41.11 51.39 59.95 68.52
80mmx120mm   21.13 26.84 36.35 45.68 57.1 66.64 76.13 85.64
100mmx120mm     29.52 39.99 50.24 62.81 73.27 83.74 94.21 104.68 125.61
120mmx120mm     32.2 43.62 54.81 68.52 79.93 91.35 102.77 114.19 137.03
50mmx150mm   21.13 26.84 36.35 45.68 57.10 66.61 76.13 85.64
100mmx150mm     35.78 45.25 57.10 71.37 83.27 95.16 107.06 118.95 142.74 166.53 190.32
150mmx150mm     40.25 54.53 68.52 85.64 99.92 114.19 128.47 142.74 171.29 199.84 228.38
80mmx160mm     32.2 43.62 54.81 68.52 79.93 91.35 102.77 114.19 137.03
80mmx180mm       65.43 82.22 102.77 119.90 137.03 154.16 171.29 205.55
100mmx200mm       54.53 68.52 85.64 99.92 114.19 128.47 142.74 171.29 199.84 228.38
150mmx200mm         79.93 99.92 116.57 133.32 149.88 166.53 199.84 233.14 266.45
150mmx300mm         102.3 125.8 148.9 170 191.4 212.6 255 297 338.7
200mmx200mm         91.35 114.19 133.22 152.26 191.29 190.32 228.38 266.45 304.51
250mmx250mm         104.19 142.74 166.53 190.32 214.11 237.9 285.48 333.06 380.64
300mmx300mm         137.03 171.29 199.84 228.38 256.93 285.48 342.58 399.67 456.77
350mmx350mm           199 231.8 264 296.
Special specifications,length and wall thickness can be customized according to customer requirements.



Description

Tube En Inox;Tig Welded Stainless Steel Pipe;Stainless steel tubes; stainless steel welded pipe; 159mm stainless steel inox round tube pipe;Tubo de acero inoxidable

Material Grade AISI201/SUS304/ AISI316
Standard

ASTM A554/JIS G3446 /CNS 5802 /EN 10217-7/EN 10296-2,EN 10305-2,EN 10305-5.

Thickness

1.0mm,1.5mm,2.0mm,2.5mm,3.0mm,3.5mm,4.0mm,5.0mm,6.0mm,customized.

Section Shape Round Shape.
Surface BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D
Length 5.85m,6m,6.1m,7m,length can be customized.
Application It widely used in auto parts, hardware tools, handicrafts, electronics, textiles, chemicals, machinery, construction, aerospace, winding various precision springs,hangers,elevator, machinery industry, shipbuilding industry, pharmaceutical industry and etc.



What industries or applications are High Temperature Resistance 159mm Inox Welded Tube AISI201 304 316 Large Diameter Round Stainless Steel Thick Wall Pipe suitable for?
The High Temperature Resistance 159mm Inox Welded Tube AISI201 304 316 Large Diameter Round Stainless Steel Thick Wall Pipe can be suitable for various industries and applications due to its high-temperature resistance and corrosion-resistant properties. Here are some industries and applications where this type of stainless steel pipe finds utility:
1. Petrochemical Industry: The pipe can be used for conveying fluids and gases in petrochemical plants, refineries, and oil and gas processing facilities.
2. Chemical Industry: It is suitable for handling corrosive chemicals and acids in chemical processing plants.
3. Food and Beverage Industry: The pipe can be used for food processing, beverage production, and dairy applications due to its hygienic properties and resistance to corrosion.
4. Pharmaceutical Industry: It finds application in pharmaceutical manufacturing, where cleanliness, hygiene, and corrosion resistance are critical.
5. Water and Wastewater Treatment: The pipe can be used for transporting water, treated wastewater, and chemicals in water treatment plants and wastewater treatment facilities.
6. Power Generation: It is suitable for various power generation applications, including thermal power plants, nuclear power plants, and renewable energy facilities.
7. Construction and Architecture: The pipe can be used in building structures, infrastructure projects, and architectural applications due to its strength, durability, and aesthetic appeal.
8. Automotive and Transportation: It finds utility in the automotive industry for exhaust systems, fuel lines, and other transportation applications requiring corrosion resistance.
9. Marine and Offshore: The pipe is suitable for marine environments, offshore oil and gas platforms, and shipbuilding due to its resistance to seawater and harsh conditions.
10. Pharmaceutical Industry: The pipe can be used for pharmaceutical manufacturing, where cleanliness, hygiene, and corrosion resistance are critical.
11. Aerospace Industry: It finds application in the aerospace industry for components requiring high-temperature resistance and corrosion resistance.
12. Mining and Minerals: The pipe can be used in mining operations and mineral processing plants, where resistance to corrosive environments is essential.
These are just a few examples, and the applications of High Temperature Resistance 159mm Inox Welded Tube AISI201 304 316 Large Diameter Round Stainless Steel Thick Wall Pipe can extend to various other industries and applications depending on specific requirements. It is important to consider the specific needs of the application and consult with industry experts or engineers to determine the suitability of the pipe for a particular use case.

High Temperature Resistance 159mm Inox Welded Tube AISI201 304 316 Large Diameter Round Stainless Steel Thick Wall Pipe 0
